Technical Specifications
| Specification | Details |
|---|---|
| Model | GF1100ND3 |
| Crucible Capacity | 1 kg & 3 kg graphite crucibles included :contentReference[oaicite:1]{index=1} |
| Max Temperature | 1 150 °C (2 102 °F) :contentReference[oaicite:2]{index=2} |
| Power Input | 1 750 W (also listed as 1 350 W variant) :contentReference[oaicite:3]{index=3} |
| Voltage | 110 V (US); EU versions compatible with local mains :contentReference[oaicite:4]{index=4} |
| Temperature Accuracy | ±1 °C controlled by PID :contentReference[oaicite:5]{index=5} |
| Heat-up Time | ~25–45 min to reach 1 150 °C :contentReference[oaicite:6]{index=6} |
| Crucible Dimensions (3 kg) | Internal Ø 5 × 16 cm; External Ø 7.5 × 17 cm :contentReference[oaicite:7]{index=7} |
| Overall Dimensions | 38 × 24 × 21 cm :contentReference[oaicite:8]{index=8} |
| Weight | 7.1 kg :contentReference[oaicite:9]{index=9} |
| Chamber Material | High-temp ceramic with quartz lid & cooling vents :contentReference[oaicite:10]{index=10} |
| Control System | PID digital with K-type thermocouple; temperature updated every 2 s :contentReference[oaicite:11]{index=11} |
Features & Benefits
- Fast & efficient melting: Up to 1 150 °C in under 45 minutes, melts metals like gold and aluminum with ease :contentReference[oaicite:12]{index=12}.
- High-purity graphite crucibles: Excellent heat conductivity, chemical resistance, and grooves for easy pouring :contentReference[oaicite:13]{index=13}.
- PID temperature control: Precise regulation with ±1 °C accuracy and display refresh every 2 seconds :contentReference[oaicite:14]{index=14}.
- Complete safety and accessory kit: Includes two crucibles (1 kg & 3 kg), ingot mold, tongs, heat-resistant gloves, and power cable :contentReference[oaicite:15]{index=15}.
- Sturdy, compact design: Quartz-lined chamber and cooling vents enhance durability.
Applications
- Jewelry casting and bar production
- Refining precious metals (gold, silver, copper)
- Small-scale metal recycling and alloy creation
- Laboratory or workshop use where precise melting is needed
Safety Guidelines
- Always use included gloves and tongs to avoid burns
- Ensure proper ventilation to handle fumes safely
- Never open the lid during melting to prevent heat loss
- Follow local disposal regulations for waste materials
Maintenance & Care
- Regularly inspect crucibles for cracks and replace as needed :contentReference[oaicite:16]{index=16}
- Clean chamber and crucibles after use to avoid residue buildup
- Store in a dry, cool environment to prolong life
Additional Information
- Variants available: 1 350 W model with similar specs :contentReference[oaicite:17]{index=17}
- Warranty & support: Details available via VEVOR technical support :contentReference[oaicite:18]{index=18}
- Customer reviews: Rated 4.0/5 based on 49 reviews :contentReference[oaicite:19]{index=19}
