Body
Build Volume : 256 × 256 × 256 mm³
Chassis : Steel + Extruded Aluminum
Toolhead
Hot End : All-Metal
Extruder Gears : Hardened Steel
Nozzle : Stainless Steel
Max Hot End Temperature : 300°C
Nozzle Diameter (Included) : 0.4 mm
Nozzle Diameter (Optional) : 0.2 mm, 0.6 mm, 0.8 mm
Filament Cutter : Yes
Filament Diameter : 1.75 mm
Heatbed
Compatible Build Plates :
- Bambu Textured PEI Plate
- Bambu Smooth PEI Plate
- Bambu High Temperature Plate (Smooth PEI)
- Bambu Cool Plate
Max Build Plate Temperature : 100°C
Speed
Max Speed of Toolhead : 500 mm/s
Max Acceleration of Toolhead : 10,000 mm/s²
Max Hot End Flow : 28 mm³/s @ABS (Model: 150 × 150 mm single wall; Material: Bambu ABS; Temperature: 280°C)
Cooling
Part Cooling Fan : Closed Loop Control
Hot End Fan : Closed Loop Control
Supported Filaments
Ideal : PLA, PETG, TPU, PVA
Not Recommended : ABS, ASA, PC, PA, PET, Carbon/Glass Fiber Reinforced Polymer
Sensors
Monitoring Camera : Low Rate Camera (up to 1080P)
Timelapse : Supported
Filament Run Out Sensor : Yes
Filament Odometry : Yes
Power Loss Recovery : Yes
Filament Tangle Sensor : Yes
Physical Dimensions
Dimensions : 385 × 410 × 430 mm³
Net Weight : 8.3 kg
Electrical Parameters
Input Voltage : 100-240 VAC, 50/60 Hz
Max Power : 1300 W @220V, 350 W @110V
Electronics
Display : 3.5-inch 320 × 240 IPS Touch Screen
Connectivity
Wi-Fi, Bambu-Bus
Storage
Micro SD Card
Control Interface
Touch Screen, APP, PC Application
Motion Controller
Dual-Core Cortex M4
Software
Slicer : Bambu Studio
Supports third-party slicers that export standard G-code (e.g., Superslicer, Prusaslicer, Cura), though some advanced features may not be supported.
Supported OS : MacOS, Windows
Wi-Fi
Frequency Range :
- 2412 MHz - 2472 MHz (CE)
- 2412 MHz - 2462 MHz (FCC)
- 2400 MHz - 2483.5 MHz (SRRC)
Transmitter Power (EIRP) : - ≤ 21.5 dBm (FCC)
- ≤ 20 dBm (CE/SRRC)
Protocol : IEEE 802.11 b/g/n
